Main technical parameter
1. Rated primary current: 50-1500A
2. Rated secondary current: 5A or 1A
3. Rated voltage: 30kV or 33kV or 34.5kV or 35kV etc
4. Accuracy class for Metering : 0.2S, 0.5S, 0.2, 0.5.
5. Accuracy class for protection: 10P10, 10P15, 10P20.
6. Standards: IEC60044-1.2003 Part 1: Instrument transformers-Part1: Current transformers
7. Other parameters pls see as follow:
|
|
LR-35 |
|
LRD-35 |
||||
|
Rated current ratio（A） |
Accuracy class and rated output(VA) |
Rated current ratio（A） |
Accuracy class and rated output(VA) |
||||
|
0.2S |
0.2 |
0.5S |
0.5 |
1 |
10P |
||
|
600-1200/5 |
15 |
15 |
20 |
20 |
|
600-1200/5 |
15-20 |
|
300-600/5 |
10 |
10 |
15 |
15 |
|
300-600/5 |
15 |
|
150-300/5 |
10 |
10 |
15 |
15 |
|
150-300/5 |
15 |
|
100-300/5 |
5-10 |
5-10 |
10 |
10 |
|
100-300/5 |
15 |
|
75-200/5 |
|
5-10 |
10 |
10 |
|
75-200/5 |
10-15 |
|
50-150/5 |
|
|
|
5-10 |
5-10 |
50-150/5 |
10-15 |
|
100-300/1 |
|
2 |
|
|
|
100-300/1 |
10 |
|
75-200/1 |
|
2 |
|
|
|
75-200/1 |
10 |
|
50-150/1 |
|
|
|
|
2 |
50-150/1 |
10 |
Remarks: Upon request we are glad to offer transformers according to other standards or with non-standard technical specs.
