JDZ-36
VOLTAGE TRANSFORMER
□ 36kV Indoor Single-Phase Epoxy Resin Type
Epoxy resin casting and double pole insulated VT, is widely used for
measuring , electric energy and protective relaying in the
isolated neutral system with the frequency 50Hz or 60Hz and
insulation voltage 36 kV (Up to 40.5kV).
The iron core adopts advanced cold-rolled silicon steel sheet. High
voltage outgoing line of primary winding was fetched out from top of
the product; outgoing line of secondary winding was fetched out
from transverse side of the product
Technical Data
1、Installation site indoor
2、Rated frequency 50/60Hz
3、Load power factor: cosΦ=0.8 （lagging）
4、Technical standard accords with IEC 60044-2
(IEC 61869-1&3)
Specification
Type
Rated
Primary Voltage(kV)
Rated
Secondary Voltage(kV)
Accuracy
classes combination
Rated output
(VA)
Thermal
limiting current
(VA)
Rated
insulation level(kV)
JDZ-36
35
33
0.11
0.2
60
1000
36/70/170
0.5
120
1
200
0.11/0.11
0.2/0.2
25/25
500/500
0.2/0.5
25/50
0.5/0.5
50/50
Outline
